Mobilith SHC™ Series

Mobilith SHC™ Series greases provide excellent adhesion, structural stability, and resistance to water, helping to reduce your maintenance costs and improve profitability.

Our Mobilith SHC™ Series multipurpose greases are high-performance synthetic lubricants developed to protect equipment in severe applications operating at extreme temperatures. Their excellent adhesion, structural stability and resistance to water make them suitable for use in a wide variety of machinery and components.

Mobilith SHC Series greases exhibit excellent wear, rust and corrosion protection, which can help to:

  • Improve mechanical efficiency
  • Enhance bearing and equipment life
  • Extend grease life
  • Reduce maintenance costs
  • Reduce energy consumption and starting torque
  • gauge

    Long relubrication intervals help minimize downtime and maintenance costs

    Learn more
  • gears

    Help promote long equipment life through resistance to rust, corrosion and wear

    Learn more
  • Industrial equipment builder

    370+ builders approve or endorse Mobilith SHC Series greases

    Learn more
  • Thermal conductivity

    Exceptional protection, even in extreme conditions, helps limit maintenance

    Learn more

Product series information

{0} offers {1} lubricant grades

Technical resources

All Mobilith SHC Series resources

Features and Benefits

The Mobil SHC brand of oils and greases are recognized and appreciated around the world for their innovation and outstanding performance. The Mobilith SHC series symbolizes ExxonMobil's continued commitment to using advanced technology to provide outstanding products. A key factor in the development of the Mobilith SHC Series were the close contacts between our scientists and application specialists with key Original Equipment Manufacturers (OEMs) to ensure that our product offerings would provide exceptional performance in the continually evolving industrial equipment designs.



Our work with equipment builders has helped confirm the results from our own laboratory tests showing the exceptional performance of the Mobilith SHC Series lubricants. These benefits include longer grease life, enhanced bearing protection and bearing life, wide temperature range of application, and the potential for improved mechanical efficiency and energy savings.



To combat high thermal exposure of the oil our product formulation scientists chose proprietary synthetic base oils for Mobilith SHC Series oils because of their exceptional thermal/oxidative resistance potential. Our scientists developed a state-of-the-art lithium complex thickener technology and used specific additives to enhance the performance of each grade of the Mobilith SHC Series product family. The Mobilith SHC Series greases offer the following features and benefits:



Features

Advantages and Potential Benefits

Outstanding high temperature and low temperature performance

Wide application temperature ranges, with excellent protection at high temperatures and low torque, easy start-up at low temperatures

Excellent protection against wear, rust and corrosion

Reduced downtime and maintenance costs because of reduced wear, rust and corrosion

Excellent thermal stability and oxidation resistance

Extended service life with longer intervals between relubrication and improved bearing life

Low traction coefficient

Potential to improve mechanical life and reduced energy consumption

Includes both high and low viscosity grades

Options for outstanding protection of slow speed, heavily loaded bearings, and options for good low temperature performance

Outstanding structural stability in the presence of water

Retains excellent grease performance in hostile aqueous environments

Low volatility

Helps resists viscosity increase at high temperatures to maximize relubrication intervals and bearing life



Applications

Application Considerations: While Mobilith SHC Series greases are compatible with most mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobilith SHC Series, it should be thoroughly cleaned out to achieve the maximum performance benefits. While the Mobilith SHC Series greases share many performance benefits, their applications are best described in terms of each product grade:

     •  Mobilith SHC 100 is an antiwear and extreme pressure grease primarily recommended for higher speed applications such as electric motors, where reduced friction, low wear and long service life are required. It is an NLGI 2 Grade / ISO VG 100 grease with a synthetic base fluid. Its operating temperature range is -40º C* to 150º C.

     •  Mobilith SHC 220 is a multi-purpose, NLGI 2 extreme pressure grease recommended for heavy-duty automotive and industrial applications. It uses an ISO VG 220 synthetic base fluid. Mobilith SHC 220 has a recommended operating temperature range of -40º C* to 150º C.

     •  Mobilith SHC 221 is a multi-purpose, extreme pressure grease recommended for heavy-duty automotive and industrial applications, particularly where centralized grease systems are utilized. It uses an ISO VG 220 synthetic base fluid. Mobilith SHC 221 has a recommended operating temperature range of -40º C to 150º C.

     •  Mobilith SHC 460 is an NLGI 1.5 Grade grease with ISO VG 460 synthetic base fluid and is an extreme pressure grease recommended for tough industrial and marine applications. It provides outstanding bearing protection under heavy loads at low-to-moderate speeds and in applications where water resistance is a critical factor. Mobilith SHC 460 has demonstrated outstanding performance in steel mills, paper mills and marine applications. The recommended operating temperature range is -30º C* to 150ºC.

     •  Mobilith SHC 1000 Special is an NLGI 2 Grade grease with ISO VG 1000 synthetic base fluid and strongly fortified with solid lubricants including 11% graphite and 1% molybdenum disulphide for maximum protection of plain or rolling element bearings operating under boundary lubrication regimes. This product is designed to extend bearing life under conditions of extremely slow speeds, sliding contacts, and high temperatures. Mobilith SHC 1000 Special has a recommended operating temperature of -30°C* to 150 °C with appropriate relubrication intervals.

     •  Mobilith SHC 1500 is an NLGI 1.5 Grade / ISO VG 1500 grease with a synthetic base fluid. It is intended for use in plain and rolling element bearings operating at extremely slow speeds, under heavy loads and high temperatures. Mobilith SHC 1500 has a recommended operating temperature range of -30 ºC* to 150 ºC with appropriate relubrication intervals. Continuous lubrication with Mobilith SHC 1500 has been very effective in prolonging bearing life in a severe roll press application. Mobilith SHC 1500 has also provided excellent performance in rotary kiln roller bearings and in slag transfer rail car bearings.

     •  Mobilith SHC 007 is an NLGI 00 Grade / ISO VG 460 grease with a synthetic base fluid; it has a recommended operating temperature range of -50º C to 150 º C with appropriate relubrication intervals. Its primary uses are in grease filled industrial gear cases subject to high temperatures, where conventional semi fluid greases will not provide acceptable lubricant life and in non-driven heavy-duty truck trailer wheel hubs.



*Low temperature claims based on ASTM D 1478 results vs. maximum limits of 10,000 / 1000 gcm @ startup and 1 hour respectively.



Specifications and Approvals



This product has the following approvals:

007

100

1500

220

221

460

AAR-M942



X





X



Siemens Gamesa Renewable Energy offshore direct drive wind turbine main bearing

X













This product is recommended for use in applications requiring:

007

100

1500

220

221

460

CEN EN 12081:2017



X











This product meets or exceeds the requirements of:

007

100

1500

220

221

460

DIN 51825:2004-06 - KP HC 1-2 N -30





X







DIN 51825:2004-06 - KP HC 1-2 N -40











X

DIN 51825:2004-06 - KP HC 2 N -30







X





DIN 51825:2004-06 - KP HC 2 N -40



X









DIN 51826:2005-01 - GP HC 00 K -30

X













Properties and Specifications

Property

007

100

1000 SPECIAL

1500

220

221

460

Grade

NLGI 00

NLGI 2

NLGI 2

NLGI 1.5

NLGI 2

NLGI 1

NLGI 1.5

Thickener Type

Lithium Complex

Lithium Complex

Lithium Complex

Lithium Complex

Lithium Complex

Lithium Complex

Lithium Complex

Color, Visual

Red

Red

Gray-Black

Red

Red

Light Tan

Red

Copper Strip Corrosion, 24 h, 100 C, Rating, ASTM D4048

1B

1B

1B

1B

1B



1B

Corrosion Preventive Properties, Rating, ASTM D1743





Pass

Pass

Pass

Pass

Pass

Dropping Point, °C, ASTM D2265



265

265

265

265

265

265

Four-Ball Extreme Pressure Test, Weld Point, kgf, ASTM D2596

250

250

620

250

250

250

250

Four-Ball Wear Test, Scar Diameter, mm, ASTM D2266

0.5

0.5

0.5

0.5

0.5

0.5

0.5

Oil Separation, 0.25 psi, 24 h @ 25 C, mass%, ASTM D1742





1

<1

2



3

Penetration, 60X, 0.1 mm, ASTM D217

415

280

280

305

280

325

305

SKF Emcor Rust Test, 10% Synthetic Sea Water, ASTM D6138



0 , 1



0 , 1

0 , 1



0 , 1

SKF Emcor Rust Test, Acidic Water, ASTM D6138



0 , 1



0 , 1

0 , 1



0 , 1

SKF Emcor Rust Test, Distilled Water, ASTM D6138

0 , 0

0 , 0

0 , 0

0 , 0

0 , 0

0 , 0

0 , 0

Viscosity @ 100 C, Base Oil, mm2/s, ASTM D445

55.6

16.3

83.7

149

30.3

30.3

55.6

Viscosity @ 40 C, Base Oil, mm2/s, ASTM D445

460

100

1000

1500

220

220

460

Viscosity Index, ASTM D2270

188

175

164

212

179

179

188

Water Washout, Loss @ 79 C, wt%, ASTM D1264



6

1

6

1.5



7



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
