Mobil SHC™ Gear Series

Mobil SHC™ Gear synthetic gear oils help reduce unplanned downtime and maintenance – a must for those difficult-to-access gearboxes.

Our Mobil SHC™ Gear synthetic gear oils protect industrial gearboxes and help extend oil life in some of the most extreme conditions. They are formulated for efficient lubrication of industrial enclosed gear drives operating under extreme conditions of load, speed and temperature.

Testing indicates these oils significantly reduce energy consumption in many gearboxes – up to 3.6 percent* versus conventional oil. These synthetic gear oils also:

  • Offer excellent compatibility with gearbox metallurgy
  • Protect against scuffing and micropitting
  • Offer excellent rust and corrosion protection
  • Work well in fine filtration, even when wet
  • gauge

    Long drain intervals help minimize downtime

  • power and energy savings

    Exceptional protection, even in extreme conditions, helps limit maintenance

  • temperature

    Minimize maintenance through exceptional protection, even in extreme conditions

Product series information

{0} offers {1} lubricant grades

Technical resources

All Mobil SHC™ Gear Series resources

Energy Efficiency logo

Features and Benefits

Mobil SHC Gear Series lubricants are part of the Mobil SHC line of products that are recognized and appreciated around the world for innovation and outstanding performance. These synthetic products, pioneered by our research scientists, symbolize the continuing commitment to using advanced technology to provide lubricants with excellent balanced performance. A key factor in the development of Mobil SHC Gear Series was the close contacts between our scientists and application specialists with key OEMs to ensure that our product offering would provide exceptional performance with rapidly evolving industrial gear designs and operation. Not least among the benefits shown in work with OEMs is the ability to resist micropitting wear which can occur with some highly loaded, case-hardened gearing applications. This cooperative work also demonstrated the all-round balanced performance benefits for the new Mobil SHC Gear technology, including a wide temperature range of application.



To address the issue of micropitting wear, our product formulation scientists designed a proprietary combination of additives which would resist traditional gear wear mechanisms as well as protecting against micropitting. Mobil SHC Gear products provide exceptional oil life and deposit control and resistance to thermal/oxidative and chemical degradation, as well as the balance of the performance features. The patent-pending combination of synthetic base oils also provides exceptional low temperature fluidity characteristics unmatched by conventional mineral oil gear lubricants and is a key benefit for remote, low ambient temperature applications. The Mobil SHC Gear Series lubricants offer the following potential benefits:



Features

Advantages and Potential Benefits

Superb protection from micropitting fatigue wear as well as high resistance to traditional scuffing wear

Helps extend gear and bearing life in enclosed gear drives operating under extreme conditions of load, speed and temperature

Helps reduce unplanned downtime; less maintenance - especially critical for difficult to access gearboxes.

Excellent resistance to degradation at high temperatures

Helps extend oil life and drain intervals and reduce oil consumption, which can lower maintenance costs

Low traction

Helps reduce energy consumption and lower operating temperatures

High viscosity index equating to reduced viscosity change with temperature

Ability to operate at both high and low temperatures: especially critical in remote applications with no oil cooling or heating

Excellent resistance to rust and corrosion and very good demulsibility

Helps to ensure smooth, trouble-free operation at high temperatures or in applications subject to water contamination

Excellent compatibility with a variety of soft metals

Excellent shear stability

Helps extend gear and bearing life

Resistence to filter plugging, even in the presence of water

Fewer filter changes; which can help reduce maintenance costs

Excellent seal compatibility

Less contamination and lower potential for oil leakage

Excellent compatibility with common gearbox materials and with mineral-based gear oils

Easy changeover from many mineral products



Applications

Application Considerations: While the Mobil SHC Gear Series are compatible with mineral oil based products, admixture may detract from their performance. Consequently it is recommended that before changing a system to one of the Mobil SHC Gear Series, it should be thoroughly cleaned out and flushed to achieve the maximum performance benefits.

Mobil SHC Gear Series exceptional performance, synthetic industrial gear oils are designed to provide optimum equipment protection and oil life even under extreme conditions. They are especially formulated to resist micropitting of modern, case hardened gearing and can operate in both high and low temperature environments. Typical applications include:

     •  Modern, highly loaded gearboxes used in the paper, steel, oil, textile, lumber and cement industries where gear protection and optimum oil life are required.

     •  Plastic extruder gearboxes

Mobil SHC Gear Series ISO VG 150, 220, 320, 460 and 680 are approved under General Electric's (GE) gear oil specification D50E35 for use in off-highway vehicle motorized wheel gearbox applications.



Specifications and Approvals

This product has the following approvals:

150

220

320

460

680

1000

Flender

X

X

X

X

X



GE OHV D50E35A/B/C/D/E

X

X

X

X

X



SEW-Eurodrive

X

X

X

X

X

X

ZF TE-ML 04H

X













This product meets or exceeds the requirements of:

150

220

320

460

680

1000

AGMA 9005-F16

X

X

X

X

X



DIN 51517-3:2018-09

X

X

X

X

X

X

ISO L-CKD (ISO 12925-1:2024)

X

X

X

X

X

X

ISO L-CTPR (ISO 12925-1:2024)

X

X











Properties and Specifications

Property

150

220

320

460

680

1000

Grade

ISO 150

ISO 220

ISO 320

ISO 460

ISO 680

ISO 1000

Brookfield Viscosity @ -17.8 C, mPa.s, ASTM D2983









41000

96000

Brookfield Viscosity @ -29 C, mPa.s, ASTM D2983

18200

35000

57000

107000

156000

500000

Copper Strip Corrosion, 24 h, 121 C, Rating, ASTM D130

1B

1B

1B

1B

1B

1B

Demulsibility, Total Free Water, for EP Oils, ml, ASTM D2711

88

87

85

84

87

82

Density @ 15.6 C, g/ml, ASTM D4052

0.86

0.86

0.86

0.86

0.86

0.87

Emulsion, Time to 37 mL Water, 82 C, min, ASTM D1401

10

10

10

15

25

40

FZG Micropitting, Fail Stage, Rating, FVA 54

10

10

10

10

10

10

FZG Micropitting, GFT-Class, Rating, FVA 54

High

High

High

High

High

High

FZG Scuffing, Fail Load Stage, A/16.6/90, ISO 14635-1(mod)



>14

>14

>14

>14

>14

FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1

>14











FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1(mod)



14

14

14

14

14

Flash Point, Cleveland Open Cup, °C, ASTM D92

233

233

233

234

234

234

Foam, Sequence II, Stability, ml, ASTM D892

0

0

0

0

0

0

Foam, Sequence II, Tendency, ml, ASTM D892

0

0

0

0

0

0

Four-Ball Extreme Pressure Test, Load Wear Index, kgf, ASTM D2783

51

51

51

51

51

51

Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2783

200

200

200

200

200

200

Kinematic Viscosity @ 100 C, mm2/s, ASTM D445

22.2

30.4

40.6

54.1

75.5

99.4

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

150

220

320

460

680

1000

Pour Point, °C, ASTM D5950

-54

-45

-48

-48

-42

-33

Rust Characteristics, Procedure B, ASTM D665

PASS

PASS

PASS

PASS

PASS

PASS

Total Acid Number, mgKOH/g, ASTM D664

0.9

0.9

0.9

0.9

0.9

0.9

Viscosity Index, ASTM D2270

176

180

181

184

192

192



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
