Mobil SHC Grease 460 WT

High Performance Synthetic Grease for Wind Turbines

Our Mobil SHC™ Grease 460 WT synthetic grease is designed to protect wind turbine equipment operating at high and low temperature extremes, including lubrication of yaw, pitch and main bearings.

In addition, Mobil SHC Grease 460 WT synthetic grease provides excellent protection against wear, rust and corrosion, and exhibits:

  • Excellent adhesion to parts
  • Structural stability of the grease thickener
  • Robust water resistance

Proven performance in

10,000+ wind turbines
wind turbine icons

Equipment lubricant recommendations

Our Mobil Serv℠ Product Selector tool will help you identify lubricant(s) for your specific equipment.

Data sheets

Product information

Features and Benefits

The Mobil SHC™ brand of oils and greases are recognized and appreciated around the world for their innovation and outstanding performance. A key factor in the development of ExxonMobil´s products was the close contacts with key Original Equipment Manufacturers (OEMs) to ensure that our product offerings would provide exceptional performance in the continually evolving industrial equipment designs.

Our work with equipment builders has helped confirm the results from our own laboratory tests showing the exceptional performance of Mobil SHC Grease 460 WT. Compared to conventional greases the benefits of this synthetic grease include longer grease life, enhanced false brinelling protection and bearing life, wide temperature range of application, and the potential for improved mechanical efficiency.

To combat severe application conditions proprietary synthetic base oils have been chosen for Mobil SHC Grease 460 WT because of their outstanding thermal/oxidative resistance potential. A state-of-the-art lithium complex thickener technology and specific additives help to enhance the performance of Mobil SHC Grease 460 WT offering the following features and benefits:



Features

Advantages and Potential Benefits

Outstanding high temperature and low temperature performance compared to conventional greases

Wide application temperature ranges, with excellent protection at high temperatures and low torque, easy start-up at low temperatures

Superb thermal stability and oxidation resistance compared to conventional greases

Extended service life with longer intervals between relubrication and improved bearing life

Excellent protection against wear, rust and corrosion

Reduced downtime and maintenance costs

Excellent pumpability

Reliable lubrication of bearings using centralized grease systems or grease dispensers

Outstanding structural stability in the presence of water

Retains excellent grease performance in hostile aqueous environment

Low traction coefficient

Synthetic formulation delivers potential improved mechanical life and reduced energy costs versus conventional greases



Applications

Mobil SHC Grease 460 WT is an NLGI 1.5 Grade extreme pressure grease with ISO VG 460 synthetic base fluid recommended for tough wind turbine applications. It provides outstanding bearing protection under heavy loads at low-to-moderate speeds and in applications where water resistance is a critical factor. Mobil SHC Grease 460 WT meets most specifications of wind turbine builder and component suppliers and has demonstrated outstanding performance in applications such as lubrication of yaw, pitch and main bearings either manual greased or using centralized grease systems or grease dispensers. The recommended operating temperature range is -30º C to 150ºC.



Specifications and Approvals

This product meets or exceeds the requirements of:

DIN 51825:2004-06 - KP HC 1-2 N -30



Properties and Specifications

Property

Grade

NLGI 1.5

Thickener Type

Lithium Complex

Base Oil Viscosity of Greases @ 40 C, mm2/s, AMS 1697

460

Corrosion, Bearing, Rating, ASTM D1743

PASS

Dropping Point, °C, ASTM D2265

255

Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2596

250

Penetration, 60X, 0.1 mm, ASTM D217

305

SKF Emcor Rust Test, Distilled Water, ASTM D6138

0,0

Timken, Minimum OK Load, lb, ASTM D2509

55

Water Washout, Loss @ 79 C, wt%, ASTM D1264

10

Color, Visual

Red



Health and safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
